EOL

VBOX-3210 (EOL)

• AMD RX-421BD Quad Core 2.1GHz up to 3.4 GHz*
• AMD RX-216GD Dual Core 1.6GHz up to 3.0 GHz (Optional GX-224IJ, GX-215JJ)
*Config to 15W

• 2 x SO-DIMM DDR4 up to 32GB (only 1 slot for GX series)

• AMD Radeon™ graphics

• 2 x Serial ATA GEN 3.0

• 2 x Intel i210-AT; Ethernet Switch: 1 x Marvell 88E6176

• 1 ~ 255 level reset

• 2 x RS232/422/485 (option additional 2 x RS232)

• 2 x USB 3.0 ports and 2 x USB2.0 Ports

• 5 x RJ45 Ports GbE (Optinal for 4 x POE 802.3at/af*)

*When Power Input ≧ 24V, total PoE outputs is 100W max. When Power Input < 24V, total PoE output is 60W max.

• 2 x DP, 1 x VGA (only for RX series)

• 4 In and 4 Out

• Mic-in/Line-out/Line-in

• 3 x Mini-card slots, 1 x M.2 A-E key 2230 (only for RX series)

• 6 x SMA-type External Antenna Connectors

• 2 x SIM Card Sockets Supported Onboard with eject

• 9V – 48V DC Power Input

• Vehicle Power Ignition for Variety Vehicle

• Power on/off Delay Time Setting by Software

• Internal Battery backup Kit for 10 Mins Operating (Optional)

• 1 x 2.5” Drive Bay for SATA Type Hard Disk Drive/SSD

• 1 x Cfast slot

• WES 7 64bit, Win 10 LTSB 1607, Ubuntu 16.04 64bit

• -40 ~ 70°C (w/SSD), ambient w/ 0.6m/s airflow

• -40 ~ 85°C

• 5 ~ 95% (non-condensing)

• IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis with SSD

• MIL-STD-810G, Method 514.6, Procedure I, Category 4

• Operating: MIL-STD-810G, Method 516.6, Procedure I, Trucks and semi-trailers=15G (11ms) with SSD

• Aluminum Alloy

• Wall-mount, Din Rail Mounting kit (Optional Internal Battery backup Kit)

• 1405g

• 240 x 161 x 85 mm

• VBOX-3210-R421 (w/RX-421BD)

• VBOX-3210-R216 (w/RX-216GD)

• AMD R-Series APU W / 2 x DP / 2 x COM / 5 x GbE / 4 x POE/ 2 x USB 3.0 / DC Input 9~48V In-Vehicle Computer

• Made in Taiwan
