Display Computer

VDM-700HD

• 7 inches / 16:9

• 1280 (H) × 720 (V) RGB

• 156.48 (H) × 80.136 (V) mm

• 80 / 80 / 80 / 80 Degree

• 560 nits (typical)

• 1000:1 (typical)Backlight Type

• LED

• Projected Capacitive with Multi-touch

• 1 x DVI-D 29 pins Connector for DVI-D Single Link Video,
Touch (USB 2.0), Line in, MIC out, and DC 9~48V Power input
* SINTRONES custom pin definition for SINTRONES optional cable only

• 1 x HDMI®

• 6 x Touch Hotkeys

• 2 x Bulit-in Digital MIC

• Stereo Speaker with Built-in Amplifier

• 188.5 (L) x 124.2 (W) x 31.4 (H) mm

• 510 g

• VESA MIS-D 75 mm

• (Front) IP65
• (others) IP4X

• 9V – 48V DC Power Input

• -20°C ~ 60°C with 0.6 m/s airflow

• -40°C ~ 80°C

• 10% RH – 90% RH (non-condensing)

• IEC60068-2-64, random, 2.5G@5~500Hz, 1hr/axis
• MIL-STD-810G, Method 514.6, Procedure I, Cat.4, Operating

• Operating: MIL-STD-810G, Method 516.6, Procedure I, Trucks and semi-trailers=15G (11ms)
